lithium battery management system
model no: bd-10s-1a-kw
application: apply to 36v li-ion battery products
feature: the protective control circuit has the protection function of overcharge, over discharge and over-current, short circuit, balance, battery temperature test and alarm.
|
item |
specification |
parameters
|
|
overcharge protection
|
detection voltage |
4.25±0.05v |
|
recovery voltage |
4.15± 0.05v | |
|
over-discharge protection
|
detection voltage |
2.7±0.05v |
|
recovery voltage |
3.0±0.05v | |
|
over-current protection
|
over-current protection current |
50±5a |
|
delay time |
200ms | |
|
unprotected condition
|
disconnect the load
|
|
|
short circuit protection
|
protected condition |
external short circuit |
|
unprotected condition |
disconnect the short-circuited circui |
|
|
balance function
|
start balance function |
4.2v±0.05v |
|
recovery balance function |
<4.2v | |
|
over temperature protection
|
over temperature protection temperature |
temperature can be set
|
|
over temperature recovery temperature |
||
|
self discharge
|
normal state |
<50ua |
|
dormancy state |
<8ua |
certifications: ce, rohs, un38.3 and other tests.
